Vehicle Details
- Bumper, front chrome
- Bumper, rear chrome with bumper CornerSteps
- Cargo ties downs (4), movable upper (Deleted when (ZW9) pickup box delete is ordered.)
- CornerStep, rear bumper
- Door handles, Black
- Glass, solar absorbing, tinted
- Grille surround, chrome
- Headlamps, halogen projector
- Lamps, cargo area, cab mounted with switch on center switch bank
- Mirrors, outside high-visibility vertical camper-style, Black with manual folding and extension and lower convex spotter glass (Not available with (PCR) Sierra Fleet Convenience Package.) (Not available with (PDD) Sierra Convenience Package.)
- Tailgate and bed rail protection caps, top
- Tailgate, locking, utilizes same key as ignition and door (Deleted with (ZW9) pickup box delete.)
- Tire carrier lock keyed cylinder lock that utilizes same key as ignition and door (Not included when (ZW9) pickup box delete or (9J4) rear bumper delete is ordered.)
- Tires, LT265/70R18E all-season, blackwall (Requires single rear wheels.)
- Wheels, 18" (45.7 cm) painted steel includes 18" x 8" (45.7 cm x 20.3 cm) steel spare wheel. Spare not included with (ZW9) pickup box delete unless a spare tire is ordered. (Requires single rear wheels, (QGM) LT265/70R18E all-terrain, blackwall tires or (QWF) LT265/70R18E all-season, blackwall tires.)
- Air conditioning, single-zone
- Assist handle, front passenger and driver on A-pillars
- Audio system feature, 4-speaker system
- Audio system, 4.2" Diagonal Color Display, AM/FM stereo with USB ports, auxiliary jack and SD card slot (Upgradeable to (IO4) 4.2" diagonal color display radio with IntelliLink.)
- Cruise control, steering wheel-mounted
- Door locks, power
- Driver Information Center 3.5-inch diagonal monochromatic display, provides warning messages and basic vehicle information
- Floor covering, Graphite-colored rubberized-vinyl
- Instrumentation, 6-gauge cluster featuring speedometer, fuel level, engine temperature, tachometer, voltage and oil pressure
- Seat trim, Vinyl
- Seats, front 40/20/40 split-bench, 3-passenger, driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar.
- Steering column, manual Tilt-Wheel
- Steering wheel
- Air cleaner, high-capacity
- Alternator, 150 amps
- Battery, heavy-duty 720 cold-cranking amps/80 Amp-hr maintenance-free with rundown protection and retained accessory power
- Cooling, auxiliary external transmission oil cooler
- Cooling, external engine oil cooler
- Differential, heavy-duty locking rear
- Engine, Vortec 6.0L Variable Valve Timing V8 SFI E85-compatible, FlexFuel capable of running on unleaded or up to 85% ethanol (360 hp [268.4 kW] @ 5400 rpm, 380 lb-ft of torque [515.0 N-m] @ 4200 rpm) with (E63) fleetside pickup box; (322 hp [240.1 kW] @ 4400 rpm, 380 lb-ft of torque [515.0 N-m] @ 4200 rpm) with (ZW9) pickup box delete (Does not include E85 capability with (ZW9) pickup box delete.)
- Exhaust, aluminized stainless-steel muffler and tailpipe
- Frame, fully-boxed, hydroformed front section
- Pickup box, Wideside
- Rear wheel drive
- Recovery hooks, front, frame-mounted, black
- Steering, Recirculating ball
- Suspension Package, Standard includes 51mm twin tube shock absorbers and 33mm front stabilizer bar
- Trailer brake controller, integrated (Standard with (E63) pickup box. Available to order with (ZW9) pickup box delete.)
- Trailering equipment Trailering hitch platform 2.5" with a 2.0" insert for HD, 7-wire harness with independent fused trailering circuits mated to a 7-way sealed connector to hook up parking lamps, backup lamps, right and left turn signals, an electric brake lead, battery and a ground, The trailer connector also includes the 4-way for use on trailers without brakes - park, brake/turn lamps (Deleted when (ZW9) pickup box delete or (9J4) rear bumper delete is ordered.)
- Air bag deactivation switch, frontal passenger-side
- Air bags, frontal, driver and right front passenger, single stage
- Daytime Running Lamps with automatic exterior lamp control
- StabiliTrak, stability control system with Proactive Roll Avoidance and traction control includes electronic trailer sway control and hill start assist
- Frame
- Frame Type: Hydroformed
- Tires
- Rear Tire Size: LT265/70R18E
- Front Tire Size: LT265/70R18E
- Spare Tire Size: LT265/70R18E
- Rear Tire Order Code: QWF
- Front Tire Order Code: QWF
- Spare Tire Order Code: ZWF
- Brakes
- Brake Type: Pwr
- Brake ABS System: 4-Wheel
- Disc - Rear (Yes or ): Yes
- Disc - Front (Yes or ): Yes
- Engine
- Engine Type: Gas/Ethanol V8
- Fuel System: Electronic Fuel Injection
- Displacement: 6.0L/366
- Engine Oil Cooler: Yes
- Engine Order Code: L96
- SAE Net Torque @ RPM: 380 @ 4200
- SAE Net Horsepower @ RPM: 360 @ 5400
- Wheels
- Rear Wheel Material: Steel
- Front Wheel Material: Steel
- Rear Wheel Size (in): 18 x 8.0
- Front Wheel Size (in): 18 x 8.0
- Spare Wheel Size (in): 18 x 8.0
- Summary
- Body Code: E63
- Body Style: Regular Cab Pickup
- Vehicle Name: GMC Sierra 3500HD
- Steering
- Steering Type: Pwr Recirculating Ball
- Steering Ratio (:1), At Lock: N/A
- Steering Ratio (:1), On Center: 16.00
- Turning Diameter - Curb to Curb (ft): 45.9
- Turning Diameter - Wall to Wall (ft): N/A
- Fuel Tank
- Fuel Tank Capacity, Approx (gal): 36.0
- Electrical
- Maximum Alternator Capacity (amps): 150
- Suspension
- Axle Type - Rear: Full-Floating
- Axle Type - Front: Independent
- Axle Ratio (:1) - Rear: 4.10
- Suspension Type - Rear: Multi-Leaf
- Suspension Type - Front: Independent
- Axle Capacity - Rear (lbs): 7050
- Axle Capacity - Front (lbs): 4400
- Spring Capacity - Rear (lbs): 7050
- Spring Capacity - Front (lbs): 4400
- Shock Absorber Diameter - Rear (mm): 51.00
- Shock Absorber Diameter - Front (mm): 51.00
- Stabilizer Bar Diameter - Front (in): 1.31
- Trailering
- Maximum Trailering Capacity (lbs): 14600
- Dead Weight Hitch - Max Tongue Wt. (lbs): 500
- Fifth Wheel Hitch - Max Tongue Wt. (lbs): 3650
- Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
- Fifth Wheel Hitch - Max Trailer Wt. (lbs): 14600
- Wt Distributing Hitch - Max Tongue Wt. (lbs): 1460
- Wt Distributing Hitch - Max Trailer Wt. (lbs): 14600
- Transmission
- Drivetrain: Rear Wheel Drive
- Trans Type: 6
- Trans Order Code: MYD
- Reverse Ratio (:1): 3.06
- Fifth Gear Ratio (:1): 0.85
- First Gear Ratio (:1): 4.03
- Sixth Gear Ratio (:1): 0.67
- Third Gear Ratio (:1): 1.53
- Fourth Gear Ratio (:1): 1.15
- Second Gear Ratio (:1): 2.36
- Trans Description Cont.: Automatic
- Weight Information
- Curb Weight - Rear (lbs): 2734
- Curb Weight - Front (lbs): 3225
- Gross Combined Wt Rating (lbs): 20500
- Gross Axle Wt Rating - Rear (lbs): 7050
- Gross Axle Wt Rating - Front (lbs): 4400
- Gross Vehicle Weight Rating Cap (lbs): 10400
- Exterior Dimensions
- Wheelbase (in): 133.60
- Cab to Axle (in): 55.16
- Height, Overall (in): 77.83
- Ground Clearance, Rear (in): 8.42
- Width, Max w/o mirrors (in): 80.12
- Front Bumper to Back of Cab (in): 117.10
- Ground to Top of Load Floor (in): 39.09
- Length, Overall w/o rear bumper (in): 224.4
- Interior Dimensions
- Passenger Capacity: 3
- Front Hip Room (in): 60.73
- Front Leg Room (in): 45.27
- Front Head Room (in): 42.80
- Front Shoulder Room (in): 66.03
- Cargo Area Dimensions
- Cargo Volume (ft³): 76.3
- Cargo Box (Area) Height (in): 21.22
- Cargo Box Length @ Floor (in): 97.76
- Cargo Box Width @ Wheelhousings (in): 51.02
